50kW Marine Prime Power Diesel Generator

This 50kW / 62.5kVA marine diesel generator set is a complete boat engine assembly specially built for vessel onboard power supply. Running at fixed 1500RPM speed for 50Hz operation, it adopts marine-grade diesel engine and water-cooled heat-exchanger cooling system matched with seawater pump for closed fresh-water circulation cooled by seawater.

Optimized for salt-fog corrosion, high humidity and heavy-vibration marine environment caused by vessel rolling and pitching. It serves as main auxiliary power or emergency backup power for fishing boats, small-medium cargo ships, working boats, ferries and yachts, supplying stable power for navigation instruments, communication devices and various ship-borne electrical loads.

Marine classification certificates including CCS, BV, ABS are optional for ship inspection and vessel registration.

• 50kW prime power / 62.5kVA, standby power 55kW / 68.75kVA, complete marine engine-alternator integrated assembly, 1500RPM rated speed for 50Hz continuous operation
• Marine water-cooled heat-exchanger system with dedicated seawater pump, fresh-water closed-loop circulation cooled by external seawater, fully adapted to ship engine-room cooling requirement
• 100% copper brushless marine alternator, H-class insulation grade, anti-condensation tropical treatment, IP23 protection grade against salt-fog and cabin humidity
• 3-phase 4-wire output, multiple voltage options: 400V, 440V, 230V for global marine vessel standards
• Marine-specific control panel, real-time monitoring voltage, current, frequency, oil pressure, coolant temperature, seawater pump status and total running hours
• Full marine-grade protection: over-voltage, under-voltage, over-current, short-circuit, low oil pressure, high-temperature, seawater flow failure alarm & auto shutdown
• 24V DC reliable electric starting system; optional auto-start function, ATS auto-transfer switch and remote monitoring module
• Heavy-duty marine anti-vibration rubber mounts to buffer hull vibration during sailing
• Salt-fog anti-corrosion coating for corrosive marine cabin atmosphere
• Compact unit layout, easy installation and maintenance inside limited ship engine-room space
• Optional certificates: CCS, BV, ABS for ship survey, bidding and customs clearance
• Optional marine silencer, parallel cabinet for multi-genset combined power supply

• Complete integrated boat engine assembly, ready-for-installation design, saves matching work for ship-yard
• 1500RPM stable rated speed, excellent continuous heavy-load performance for long-time sea voyage
• Professional seawater cooling assembly with heat-exchanger and seawater pump, reliable heat dissipation under marine working conditions
• 100% copper marine alternator features low temperature-rise, high generating efficiency and long service-life under salt-fog and humid cabin environment
• Full marine-oriented modification: anti-corrosion painting, vibration-absorbing mounts, seawater flow monitoring, adapts to complex ship rolling and pitching environment
• Support marine classification certificates, satisfy official ship inspection, vessel registration and marine-project tender requirements

Ocean-going fishing vessels, small-medium cargo ships, passenger ferries, coastal working boats, luxury yachts, providing main-use auxiliary power and emergency standby power for navigation, lighting, communication and ship-borne electrical equipment.
