154kW Prime Power Ship Diesel Generator With 3 Phase 4 Wire Heat Exchanger Cooling

This 154kW / 192.5kVA marine diesel generator set is a complete boat engine-alternator assembly designed for harsh salt-fog, high-humidity, and heavy-vibration onboard conditions with vessel rolling and pitching. Equipped with a 3-phase brushless dynamo alternator, optional inverter module for pure-sine-wave stable output, and marine heat-exchanger cooling system with bronze seawater pump for closed fresh-water circulation cooled by seawater. The open-frame layout provides excellent heat dissipation and convenient maintenance inside ship engine rooms. Suitable as main-use auxiliary power or emergency backup power for fishing vessels, cargo ships, tugboats, ferries, and work boats. CCS, BV, ABS marine classification certificates are optional for ship inspection, vessel registration, and marine-project tender.

• 154kW prime power / 192.5kVA, standby power 169.4kW / 211.75kVA, heavy-duty marine diesel engine, inline 6-cylinder turbocharged intercooled, stable long-time continuous heavy-load performance for sea-going operation
• Complete marine cooling assembly: heat-exchanger matched with corrosion-resistant seawater pump, fresh-water closed-loop circulation cooled by raw seawater
• 3-phase 4-wire brushless dynamo alternator, 100% copper winding, H-class insulation grade, IP23 anti-salt-fog protection; optional three-phase inverter module supplies clean pure-sine-wave power for sensitive marine electronic equipment
• 50Hz / 60Hz optional, multiple voltage options: 400V, 440V, 480V to satisfy global marine vessel power standards
• Marine-specific digital control panel, real-time monitoring voltage, current, frequency, oil pressure, coolant temperature, seawater pump working status and total running hours
• Full marine-grade protection: over-voltage, under-voltage, over-current, short-circuit, overspeed, low oil pressure, high-temperature, seawater flow failure alarm & auto shutdown
• 24V DC reliable electric starting system; optional auto-start, ATS auto-transfer switch and remote monitoring function
• Heavy-duty marine anti-vibration rubber mounts to isolate hull vibration transmission
• Salt-fog anti-corrosion coating for corrosive humid marine cabin atmosphere
• Compact integrated assembly, easy installation for ship-yard
• Optional marine silencer, parallel cabinet for multi-genset parallel operation
• Certificates: CCS, BV, ABS optional for ship survey and customs clearance

• Heavy-duty marine-grade engine, proven reliability for long-hour continuous operation at sea
• 3-phase dynamo alternator with optional inverter provides clean stable power for navigation instruments and sensitive marine loads
• Professional heat-exchanger plus seawater pump cooling system, stable heat dissipation under marine seawater cooling condition
• 100% copper brushless alternator features low temperature-rise, high generating efficiency and long service-life under salt-fog corrosive environment
• Full marine-oriented modification: anti-corrosion painting, vibration-absorbing mounts, seawater flow monitoring, adapt to complex ship rolling-pitching environment
• Support marine classification certificates, meet ship-yard inspection, vessel registration and offshore-project tender requirements

Ocean-going fishing vessels, medium-size cargo ships, tugboats, passenger ferries, coastal working crafts; supplies main-use auxiliary power and emergency backup power for navigation equipment, communication system, lighting and all ship-borne electrical devices.
